SPECIFICATIONS

Brand Name: YOTTAMASTER

Origin: Mainland China

Hign-concerned Chemical: None

Case Material: aluminum

Plug Type: EU Plug

Plug Type: US PLUG

Plug Type: AU Plug

Plug Type: UK Plug

Supporting Hard Drive Capacity: 80TB (Single 16TB)

External Interface: USB

Internal Interface: SATA

Model Number: FS4C3

Package: Yes

Size: 2.5"

Size: 3.5"

100% Original: Yottamaster SATA HDD SSD Case

High Quality: 2.5"/3.5"inch Hard Drive Enclosure

Support System: Windows / Mac /Linux

Interface and Speed: USB3.1 GEN2 Type-C 10Gbps x 2

New Arrival: 80mm Silent fan (12V, 2PIN)

Fast Shipping: 150W Hard Disk External Case

10Gbps Ultra-Fast Speed HDD SSD Case

HDD Enclosure Adopts USB3.1 GEN2 (Type-C) Protocol with A Transfer Speed up to 10Gbps (Max)

150W SSD HDD External Case

The Strong Power Supply Can Provide Output in 150W Rated Power, Which Can Ensure Stable Operation Of Hard Drives When You Insert Five 18TB HDDs Into The Enclosure.

270TB Professional Grade SSD HDD Storage Box

Allowing Daisy-Chain Up To 2 Of These Capacity Devices Together For Up To A Enormous 270TB Of Space.

80mm Fan Dissipates Heat Efficiently

Honeycomb Cooling Holes With 80*80mm Silent Fan For Additional Cooling Power, The Fan Adjusts its Speed Automatically Based on the Hard Drive's Temperature.

Enterprise-Class Hard Disk Case

Integrated Intelligent Module Protection Greatly Reduces The Risk Of Data Loss Ensure Data Security And Stable Transmision.

Smart Dual Core Chip

Adopt the industry-core engineering chip JMS578, with JMB394 dual-chip design, Good transmission performance and stability.

Easy Installation 2.5''3.5'' SSD HDD Case

Designed to house up to five 2.5-inch or 3.5-inch drives, the universal removable metal trays is for easy installation of the HDD/SSD.

Blue light: Power on
Blue light flashing: Reading &writing
Red light: Hard drive error

Wide Compatibility SATA Enclosure

Suitable for Both 2.5" and 3.5" SATA Hard Drive.

Compatible with Windows / Linux / Mac System

Notes for Daisy-chain

(1) Please backup your data first to avoid data loss caused by formatting the hard drive.

(2) Each device needs to be connected to an AC power supply separately. "Main" port refers to the main data transfer port and "HUB" port is the serial port.

(3) Connect the computer and the "Main" portof the enclosure(device 1) with the supplied data cable.

(4) Connect the "HUB" port of the enclosure (device 1) to the "Main" port of the enclosure (device2) with the C to C data cable.

(5) And if you need to connect one more device, repeat step 4 to complete the connection.
